Image is representational - see mfr. specs
FN2070-3-06
TE Connectivity / SCHAFFNER EMC
The FN2070-3-06 is a two-stage, chassis-mount EMI filter with a rated current of 3A, designed for high differential and common ...
Scheda dati ACCESSORI Notify Me
RoHS Compliant
Box Imballaggio
Certificate of Compliance Guarantee
Descrizione
+
The FN2070-3-06 is a two-stage, chassis-mount EMI filter with a rated current of 3A, designed for high differential and common-mode attenuation.
Search Keywords: FN2070306
Specifiche
+
-
Product AttributeAttribute Value Select Attribute
-
fornitore:TE Connectivity / SCHAFFNER EMC
-
Codice componente:FN2070-3-06
-
Alias/AKA:800576-SF
-
Unità di misura:per Each
-
RoHS :Yes
-
HTS:8504508000
-
COO:TH
-
ECCN:EAR99
-
Supplier Standard Pack:
20 -
Mounting:Flange Mount
-
Maximum Voltage Rating:250 VAC
-
Maximum Current Rating:3 A
-
Operating Frequency:0 to 400 Hz
-
Operating Temperature:-25 to 100 °C
-
Dimension:85 x 54 x 40.3 mm
Tools/3D Models
+
-
EE CASSETTA DEGLI ATTREZZI
risorse
+
Scheda dati
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
in magazzino:
70
Può essere spedito immediatamente
15 Weeks
Può spedire
28/8/26
PRICE (EUR)
QTÀ
Prezzo unitario
1
€52.93
5
€35.73
20
€26.40
40
€24.78
60
€24.08
100
€23.19
260 +
€22.01
