Pulse Transformers

MDL,SIN,10GD,1:1,SM,TR NPB

XFMR OCT T1, YUBA, 1:2/1:1, SMT, MSL4,T&R RPB

Active Part but Not Recommended for New Designs, use H7019NLT (same form, fit, function)

Pulse Transformer 1:1 0.62Ohm Prim. DCR 0.75Ohm Sec. DCR 80pF 4Term. PC Pin Thru-Hole

Pulse Transformer 1.5:1 3750Vrms 0.875Ohm Prim. DCR 0.35Ohm Sec. DCR 6Term. PC Pin Thru-Hole

Pulse Transformer 1:1:1 1500VAC 0.7Ohm Prim. DCR 0.7Ohm Sec. DCR 25pF 6Term. PC Pin Thru-Hole

Pulse Transformer 3:1:1 2.8Ohm Prim. DCR 0.9Ohm Sec. DCR 9pF 6Term. PC Pin Thru-Hole

XFMR,SIN,10D,1:2,SMT,TU NPB

Pulse Transformer 3:1:1 2Ohm Prim. DCR 0.7Ohm Sec. DCR 9pF 6Term. PC Pin Thru-Hole

Active Part but Not Recommended for New Designs, use H1197NL (same form, fit, function)
