Available Replacements
ROHs Equivalent
교체 권장
Image is representational - see mfr. specs
DSP1-DC24V
Panasonic Electronic Components
Electromechanical Relay 24VDC 1.92KOhm 5A SPST-NO/SPST-NC (20.2x11x10.5)mm THT Power Relay
데이터 시트 액세서리 Notify Me
유해물질 제한지침(RoHS) 미준수
Discontinued & Replaced
Bulk 포장
설명
+
Electromechanical Relay 24VDC 1.92KOhm 5A SPST-NO/SPST-NC (20.2x11x10.5)mm THT Power Relay
Search Keywords: DSP1DC24V
사양
+
-
Product AttributeAttribute Value Select Attribute
-
공급자:Panasonic Electronic Components
-
부품 번호:DSP1-DC24V
-
측정 단위:Per Each
-
유해물질 제한지침(RoHS):No
-
HTS:8536410020
-
COO:JP
-
ECCN:EAR99
-
공급자 표준 포장:
50 -
Relay Construction:Non-Latching
-
AC Coil Voltage:N/A
-
DC Coil Voltage:24 V
-
Contact Arrangement:SPST-NO,SPST-NC
-
Maximum Current Rating:5 A
-
Mounting:Through Hole
-
Termination Style:PC Pin
-
Push to Test Button:No
-
Led Indicator:No
-
Operating Temperature:-40 to 65 °C
-
Coil Resistance:1.92 KOhm
Tools/3D Models
+
-
EE 툴박스
데이터 시트
Transportation Guide
-
This product is discontinued, but still in stock.
-
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
