Available Replacements
Older Equivalent
Image is representational - see mfr. specs
D4D07
Sensata / Crydom
Solid State Relay - 1-DC Series - 3.5-32 VDC Control Voltage Range - 7 A Maximum Load Current - 1-400 VDC Operating Voltage Ra ...
データシート アクセサリー Notify Me
RoHS遵守
EACH 包装
Certificate of Compliance Guarantee
説明
+
Solid State Relay - 1-DC Series - 3.5-32 VDC Control Voltage Range - 7 A Maximum Load Current - 1-400 VDC Operating Voltage Range - Screws And Clamps Termination - Panel Mount.
Search Keywords: D4D07
仕様
+
-
Product AttributeAttribute Value Select Attribute
-
サプライヤー:Sensata / Crydom
-
部品番号:D4D07
-
測定単位:Per Each
-
RoHS:Yes
-
HTS:8536490080
-
COO:MX
-
ECCN:EAR99
-
サプライヤー標準パック:
20 -
Output Type:DC
-
Maximum Output Voltage:400 V
-
Maximum Output Current:7 A
-
Output Device:MOSFET
-
Input Type:DC
-
Input Voltage:32 V
-
Mounting:Screw
-
Circuit Arrangement:N/A
-
Dimension:45.7 x 58.4 x 23 mm
Tools/3D Models
+
-
EE ツールボックス
CAD Drawing
データシート
Selecting a SSR
Product Changes
+
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
在庫:
39
Ships today, if you order in
8 Weeks
出荷できます
7/14/26
45ドルフラットレート配送:
PRICE (USD)
数量
Unit Price
1
$99.24
5
$98.10
10
$92.52
20
$91.79
60
$88.32
100 +
$87.88
