A Series - 4 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel - vertical PCB mount, color coding possible
The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These
Product Highlights:
- Smallest XLR receptacles, highest packing density
- Plastic housing, steel latch lock
- Fork type female contact
- Polished contact areas and hard gold plating
- Housing flammability UL94HB
Search Keywords: NC4FAV
仕様
+
-
Product AttributeAttribute Value Select Attribute
-
サプライヤー:NEUTRIK
-
部品番号:NC4FAV
-
測定単位:Per Each
-
RoHS:Yes
-
HTS:8536694040.00
-
COO:HU
-
ECCN:EAR99
-
サプライヤー標準パック:
100 -
Type:XLR Connector
-
Gender:F
-
Body Orientation:Straight
-
Mounting:Through Hole
-
Housing Material:Polyamide 6/6
-
Number of Contacts:4
-
Contact Plating:AuCo Over NiP15
-
Termination Method:Solder
-
Operating Temperature:-30 to 80 °C
Tools/3D Models
+
-
EE ツールボックス
データシート
Neutrik Meaningful Part Numbering System
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
在庫:
173
Ships today, if you order in
工場在庫:
100
出荷できます
Minimum Order Quantity:
5
3 Weeks
出荷できます
5/27/26
45ドルフラットレート配送:
PRICE (USD)
数量
Unit Price
5
$7.68
50
$7.36
100
$5.76
300
$5.31
500
$5.28
1,000
$5.14
2,500
$5.12
5,000 +
$5.09
Click for Quote
