640385-3

TE Connectivity / AMP Brand

03P MTA156 HDR ASSY SQ R/A

+ see all

Scheda dati ACCESSORI Notify Me

RoHS Compliant

Pack Imballaggio

Certificate of Compliance Guarantee

Descrizione +

03P MTA156 HDR ASSY SQ R/A

Product Highlights:

MTA-156 Connectors
Number of Positions = 3
Mating Type = Header
Wire-to-Board Application
3.96 mm Contact Centerline Spacing

Potential Applications:

Search Keywords: 6403853

Specifiche +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
fornitore:

TE Connectivity / AMP Brand
Codice componente:

640385-3
Unità di misura:

per Each
RoHS :

Yes
HTS:

8536694040
COO:

CN
ECCN:

EAR99
Supplier Standard Pack:

1650
Type:

Unshrouded Header
Body Orientation:

Right Angle
Gender:

HDR
Mounting:

Through Hole
Pitch:

3.96 mm
Number of Contacts:

3
Maximum Voltage Rating:

600 VAC
Maximum Current Rating:

7/Contact A
Termination Method:

Solder
Operating Temperature:

-55 to 105 °C

Tools/3D Models +

3D PDF

EE CASSETTA DEGLI ATTREZZI

risorse +

Product Drawing - MTA-156 HEADER ASSEMBLY, PLAIN, RIGHT ANGLE, .045 SQUARE POST, TIN PLATED

Scheda dati

Agency Approval Document - LACE-N-LOK CONNECTOR REPORT

Agency Approval Document

Agency Approval Document

Product Specification - MTA 156 Connectors

Agency Approval Document - SL.156 Connectors

Product Specification - System, Connector/Header, MTA 156

Product Changes +

PCN - 17-Sep-2012 - Mta-156 Header. Changing Pin Length Back To 0.650

PCN - 16-Mar-2020 - Additional Manufacturing Location

PCN - 28-May-2012 - Reduce Pin Length .100'' On The Connector Side Of Header
