3AC6-D8

Honeywell

MICRO SWITCH™ Door Switches: AC Series, Single Pole Double Throw (SPDT), 15.1 A 125/250 Vac, 3 Position (Push-Momentary, Pull- ...

+ see all

Scheda dati ACCESSORI Notify Me

RoHS Compliant

Imballaggio

Certificate of Compliance Guarantee

Descrizione +

MICRO SWITCH™ Door Switches: AC Series, Single Pole Double Throw (SPDT), 15.1 A 125/250 Vac, 3 Position (Push-Momentary, Pull-Maintained), 6-32 UNC Threaded Steel Rod Actuator, Supplied with V3 Basic Switch, 4,75 mm x 0,50 mm [0.187 in x 0.020 in] Quick Connect Termination

Product Highlights:

Automatically cuts power when service door or drawer is opened
Choice of momentary, maintained or pull-to-cheat actuation
Versatile mounting bracket for side or end mounting
Current rating ranges from 5 A to 25 A
Available with one or two SPDT switches
UL recognized versions available
Choice of termination

Potential Applications:

Appliances
Vending machines
Office equipment
Computer/business equipment
Test instruments
Medical/dental equipment
Communications equipment
HVAC equipment

Search Keywords: 3AC6D8

Specifiche +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
fornitore:

Honeywell
Codice componente:

3AC6-D8
Unità di misura:

per Each
RoHS :

Yes
HTS:

85365080
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

10
Type:

Door Interlock
Actuator Style:

Rod
Pole Throw Configuration:

SPDT
Maximum Current Rating:

15.1@250VAC A
Terminal Type:

Quick Connect
Operating Temperature:

-18 to 82 °C
IP Rating:

N/A
Dimension:

52.32 x 12.7 x 45.97 mm
Switch Configuration:

N.O./N.C.
Body Orientation:

Straight
