1HE1-6 by honeywell
Image is representational - see mfr. specs

1HE1-6

Honeywell

MICRO SWITCH™ Hermetically Sealed Limit Switches: HE Series, Double Pole Double Throw (DPDT), 5 A 28 Vdc, 5/8-24 UNEF Thread B ...

+ see all

Scheda dati ACCESSORI Notify Me

RoHS Compliant
Imballaggio
Certificate of Compliance Guarantee
This product may require extra documentation. Shipping may be delayed 1-2 days.
Descrizione +
MICRO SWITCH™ Hermetically Sealed Limit Switches: HE Series, Double Pole Double Throw (DPDT), 5 A 28 Vdc, 5/8-24 UNEF Thread Bushing with Corrosion Resistant Steel Pin Plunger, (6) 1829 mm [72 in] Lead Wire Termination (20 Gage) Side Exit, Leads Marked with Circuit and Gage, Military Part Number M8805/80-01
Product Highlights:
  • Meets or exceeds mechanical and electrical life as defined in MIL-S-8805
  • Meets sand and dust, explosion, icing, minimum current, and moisture resistance requirements
  • Top plunger and roller plunger actuators have an internal ice scraper ring
  • Variety of actuators and terminations
  • Variety of contact options and contact materials
  • Stainless steel housing
Potential Applications:
  • Jet aircraft de-icer controls
  • Military aircraft wingfold actuators
Search Keywords: 1HE16
Specifiche +
  • Product Attribute
    Attribute Value Select Attribute
  • fornitore:
    Honeywell
  • Codice componente:
    1HE1-6
  • Alias/AKA:
    M8805/80-01
  • Unità di misura:
    per Each
  • RoHS :
    Yes
  • HTS:
    85365000
  • COO:
    US
  • ECCN:
    9A991.d
  • Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    1
  • Type:
    N/A
  • Actuator Style:
    Top Plunger
  • Pole Throw Configuration:
    DPDT
  • Switch Configuration:
    N.O./N.C.
  • Operating Force:
    53.38 N
  • Maximum Current Rating:
    5@28VDC A
  • Terminal Type:
    Wire Lead
  • NEMA Standard as Enclosure Rating:
    N/A
  • Body Orientation:
    Straight
Tools/3D Models +
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
in magazzino: 3
Può essere spedito immediatamente
su ordine:
6   Può spedire 10/1/28
105 Weeks Può spedire 19/6/28
Aggiungi al carrello
PRICE (EUR)
QTÀ
Prezzo unitario
1
€1,562.56
3
€1,554.86
5 +
€1,547.23
