Image is representational - see mfr. specs
CB1AH-M-12V
Panasonic Electronic Components
Relays 12VDC 103Ohm 40A SPST-NO(30mm 22mm 52mm) Bracket Automotive Relay Automotive
Fiche technique ACCESSOIRES Notify Me
RoHS Compliant
Certificate of Compliance Guarantee
Description
+
Relays 12VDC 103Ohm 40A SPST-NO(30mm 22mm 52mm) Bracket Automotive Relay Automotive
Search Keywords: CB1AHM12V
spécification
+
-
Product AttributeAttribute Value Select Attribute
-
fournisseur:Panasonic Electronic Components
-
Référence:CB1AH-M-12V
-
Unité de mesure:Per Each
-
RoHS:Yes
-
HTS:8536410020
-
COO:JP
-
ECCN:EAR99
-
Référence:
50 -
Contact Form:SPST-NO (1 Form A)
-
Relay Construction:Non-Latching
-
Max Contact Current:40A
-
Coil Voltage:12 VDC
-
Coil Current:117 mA
-
Coil Resistance:103 Ohm
-
Contact Material:Silver(Cadmium Free)
-
Must Operate Voltage:7 VDC
-
Must Release Voltage:4.2 VDC
-
Operate Time:15 ms
-
Seal:Sealed
-
Mounting:Bracket Mount
-
Termination Style:0.25 Quick Connect
-
Dimension:30 x 22 x 52 mm
-
Operating Temperature:-40 to 85 °C
-
Packaging:Carton
Tools/3D Models
+
-
BOÎTE À OUTILS EE
ressources
+
Fiche technique
Transportation Guide
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
en stock:
190
Expédition aujourd'hui, if you order in
sur commande:
1 000
Peut expédier 22/10/26
Commande min Quantitè:
50
multiple:
50
24 Weeks
Peut expédier
29/10/26
PRICE (EUR)
QTÉ
Prix unitaire
50
€3.69
100
€3.65
250
€3.61
500
€3.60
1 000
€3.59
2 500
€3.59
5 000
€3.58
7 500 +
€3.57
