GS100701

Gear Tooth Speed Sensors

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

RoHS Compliant
BOX Packaging
Certificate of Compliance
Description +
Gear Tooth Speed Sensors
Product Highlights:
  • Sense Motion of Ferrous Geartooth Targets
  • Near-Zero Speed Sensing Capability
  • Immune to Hostile Environments
  • Subject to Rotational Orientation
  • High-Speed Capability
  • Operate from 5 to 24Vdc
  • Reverse Battery Protection to 24Vdc
  • Wide Operating and Storage Temperature Range
  • Sinking (Open Collector) Output
Search Keywords: GS100701
SPECS +
Product Attribute Attribute Value Select Attribute
Supplier: ZF Electronic Systems
Part No: GS100701
Unit of Measure: Per Each
RoHS: Yes
HTS: 8543704000
COO: MX
ECCN: EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution. 25
Magnetic Type: Unipolar
Maximum Output Current: 20 mA
Mounting: Panel
Output Type: Sink
Output Driver: NPN
Product Type: Digital
Dimension: 25mm x 12mm dia
Typical Operating Supply Voltage: 5 to 24 V
Termination Type: Wire Leads
Operating Temperature: -40 to 125 °C
Symbol, Footprint, 3D Model
Tools/3D Models +
Frequently Asked Questions
Is GS100701 RoHS compliant?
Yes, GS100701 is RoHS compliant.
What is the lead time for GS100701?
The standard lead time for GS100701 is approximately 20 weeks. In-stock quantities ship from OnlineComponents.com.
