RM805524 by te connectivity / p-b brand
Image is representational - see manufacturer specifications

TE Connectivity / P&B Brand Authorized Distributor

RM805524

Power Relay - 2 form C (2 CO) - 24VAC Coil - 25A Contact Rating - 400VAC Switching - 0.250" (6.3mm) Quick Connect Termination ...

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

RoHS Compliant
Discontinued
Packaging
Certificate of Compliance
Description +
Power Relay - 2 form C (2 CO) - 24VAC Coil - 25A Contact Rating - 400VAC Switching - 0.250" (6.3mm) Quick Connect Termination - Chassis Mount.
Product Highlights:
  • RM8 Series
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Current Rating = 25 Amps.
  • Monostable Coil Magnetic System
  • Input Voltage = 24 VAC
Search Keywords: RM805524
SPECS +
Product Attribute Attribute Value Select Attribute
Supplier: TE Connectivity / P&B Brand
Part No: RM805524
Alias/AKA: 2-1393147-9
Unit of Measure: Per Each
RoHS: Yes
HTS: 8536410050
COO: AT
ECCN: EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution. 1
Relay Construction: Non-Latching
AC Coil Voltage: 24 V
Contact Arrangement: DPDT
Mounting: Bracket Mount
Termination Style: 0.25Quick Connect
Push to Test Button: No
Led Indicator: No
Operating Temperature: -45 to 45 °C
Symbol, Footprint, 3D Model
Tools/3D Models +
Frequently Asked Questions
Is RM805524 discontinued?
Yes, RM805524 from Te Connectivity / P-B Brand is discontinued (end-of-life June 2018). OnlineComponents.com is an authorized distributor and may have remaining stock or a recommended replacement for it.
Is RM805524 RoHS compliant?
Yes, RM805524 is RoHS compliant.
What is the lead time for RM805524?
The standard lead time for RM805524 is approximately 25 weeks. In-stock quantities ship from OnlineComponents.com.

  • This product is discontinued, but still in stock.

Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 10
Can Ship immediately Buy all 10 in-stock or the regular minimum order quantity of 25
Stock lot only:
10
Minimum Order Quantity:
25
ADD TO CART
Request Quote
Price (USD)
Qty
Unit Price
1
$9.097
25
$8.270
50
$7.770
100
$7.660
250
$7.450
500
$7.360
1,000 +
$7.310
