66360-3

Name: 66360-3 Te Connectivity Amp Brand Connector Contact
Brand: Te Connectivity Amp Brand
SKU: 10467521
Availability: InStock

Socket Contact - Multimate III+ Series - 14 to 18 AWG - Brass Contact with 15.0µin (0.38µm) Gold Contact Finish - Crimp Termin ...

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

Datasheet Assistant

Answers are limited to this part. Verify critical specs against the datasheet.

RoHS Compliant

BOX Packaging

Certificate of Compliance

Description +

Socket Contact - Multimate III+ Series - 14 to 18 AWG - Brass Contact with 15.0µin (0.38µm) Gold Contact Finish - Crimp Termination.

Product Highlights:

Socket
Gold (15) over Nickel (50) Contact Mating Area Plating Material
Wire Range = 0.80-2.00² [18-14] mm [AWG]
Insulation Diameter = 2.03 - 2.54 mm
Brass Contact Base Material

Potential Applications:

Search Keywords: 663603

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

66360-3
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536904000
COO:

MX
ECCN:

EAR99
Supplier's Standard Package:

1000
Contact Type:

Power
Gender:

SKT
Contact Size:

16
Wire Size:

14-18 AWG
Contact Material:

Brass
Contact Plating:

Gold over Nickel
Maximum Current Rating:

N/A
Termination Method:

Crimp

Symbol, Footprint, 3D Model

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - SOCKET ASSEMBLY, LOOSE PIECE, TYPE III+

Datasheet

Product Specification - Type III+ (Size 16) Contacts

Product Specification - Evaluation Testing of PdNi and Au Plated Type III+ Multimate Contacts

Product Specification - Type III+ Stamped and Formed Contacts

Instruction Sheet - Selection of Multimate Pin and Socket Contacts

Product Changes +

PCN - 28-Jun-2012 - Type IIi+ Socket Contacts. Change The Plating In The Wire Crimp Area From Gold Flash To Matte Tin

PCN - 18-Jun-2012 - Change The Plating Located In The Wire Crimp Area Of These Contacts From Gold Flash To Matte Tin

PCN - 13-Apr-2022 - Process Change Notification

PCN - 15-Apr-2015 - Manufacturing Location Change

PCN - 30-Jun-2015 - Loose Piece Type IIi+ Contacts, Change The Revision Of The Following Parts From H To Ah

PCN - 15-Apr-2015 - MANUFACTURING LOCATION CHANGE(S)

Product Change Notification
