Image is representational - see mfr. specs
643228-1
TE Connectivity / AMP Brand
03P UMNL HDR ASSY R/A 94VO
Datasheet Accessories Notify Me
RoHS Compliant
Box Packaging
Certificate of Compliance Guarantee
Description
+
03P UMNL HDR ASSY R/A 94VO
Product Highlights:
- Header
- Universal MATE-N-LOK, Universal MATE-N-LOK II
- Not CompactPCI
- 6.35 mm Centerline, Matrix
- Number of Circuits = 3
Search Keywords: 6432281
SPECS
+
-
Product AttributeAttribute Value Select Attribute
-
Supplier:TE Connectivity / AMP Brand
-
Part No:643228-1
-
Unit of Measure:Per Each
-
RoHS:Yes
-
HTS:8536694040
-
COO:CN
-
ECCN:EAR99
-
Supplier Standard Pack:
280 -
Type:Power
-
Body Orientation:Right Angle
-
Mounting:Through Hole
-
Gender:SKT
-
Number of Contacts:3
-
Termination Method:Solder
-
Maximum Voltage Rating:600,600 VDC|VAC
-
Maximum Current Rating:19/Contact A
-
Operating Temperature:N/A
3D PDF
EE ToolBox
Product Guides
+
Product Drawing - SOCKET HEADER ASSEMBLY, RIGHT ANGLE MOUNT,3 POSITION, UNIVERSAL MATE-N-LOK(TM)
Datasheet
Product Specification - Application Specification - Universal MATE-N-LOK* Connectors
Instruction Sheet - Instruction Sheet - Universal MATE-N-LOK* Connectors
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock:
5,010
Ships today, if you order in
Minimum Order Quantity:
10
12 Weeks
can ship
7/23/26
Price (USD)
Qty
Unit Price
10
$2.362
100
$1.606
280
$1.559
560
$1.551
1,120
$1.543
2,520
$1.536
5,040
$1.528
7,560 +
$1.520
Click for Quote
Log in
to unlock special pricing
Tariffs may apply for U.S. shipments
