5747844-3

Name: 5747844-3 Te Connectivity Amp Brand DSubminiature
Brand: Te Connectivity Amp Brand
SKU: 10434063
Availability: InStock

D Sub Connector - DB9 - Size 1 - 9 Contacts - Receptacle - Solder - Right Angle - Front Metal Shell - AMPLIMITE HD-20 Series.

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

Datasheet Assistant

Answers are limited to this part. Verify critical specs against the datasheet.

RoHS Compliant

TRAY Packaging

Certificate of Compliance

Description +

D Sub Connector - DB9 - Size 1 - 9 Contacts - Receptacle - Solder - Right Angle - Front Metal Shell - AMPLIMITE HD-20 Series.

Product Highlights:

Number of Positions = 9
Receptacle
PCB Mount Angle = Right Angle
Product Series = HD 20
With Mating Connector Lock

Potential Applications:

Search Keywords: 57478443

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

5747844-3
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536694040
COO:

MX
ECCN:

EAR99
Supplier's Standard Package:

130
Type:

D-Subminiature
Body Orientation:

Right Angle
Mounting:

Through Hole
Gender:

SKT
Termination Method:

Solder
Shell Size:

1
Number of Contacts:

9
Contact Plating:

Gold over Nickel
Operating Temperature:

-55 to 105 °C

Symbol, Footprint, 3D Model

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - RECEPTACLE ASSEMBLY, SIZE 1, RIGHT ANGLE, .318 SERIES, FRONT METAL SHELL, .026 DIA POSTS, BOARDLOCKS, AMPLIMITE HD-20

Datasheet

Product Specification - AMPLIMITE Right-Angle Front Metal Shell Connectors

Product Specification - Connector, AMPLIMITE HD-20, Printed Circuit Board Mounted

Product Specification - High Performance Modular Plugs & Jacks, PCB Mounted

Agency Approval Document - AMPLIMITE D-SUBMINIATURE TYPE CONNECTORS REPORT

Product Specification - AMPLIMITE HD-20 PCB Mounted Connector

Instruction Sheet - AMPLIMITE .050 Series Connectors (Round-to-Flat Cable)
