Image is representational - see mfr. specs
5747091-2
TE Connectivity / AMP Brand
09 RCPT ACT PIN/MS MED SCRLK
Datasheet Accessories Notify Me
RoHS Compliant
Tray Packaging
Certificate of Compliance Guarantee
Description
+
09 RCPT ACT PIN/MS MED SCRLK
Product Highlights:
- Number of Positions = 9
- Receptacle
- PCB Mount Angle = Vertical
- Product Series = HD 20
- With Mating Connector Lock
Search Keywords: 57470912
SPECS
+
-
Product AttributeAttribute Value Select Attribute
-
Supplier:TE Connectivity / AMP Brand
-
Part No:5747091-2
-
Unit of Measure:Per Each
-
RoHS:Yes
-
HTS:8536694040
-
COO:CN
-
ECCN:EAR99
-
Supplier Standard Pack:
130 -
Type:D-Subminiature
-
Body Orientation:Straight
-
Mounting:Through Hole
-
Gender:SKT
-
Termination Method:Solder
-
Shell Size:1
-
Number of Contacts:9
-
Contact Plating:Gold over Nickel
-
Operating Temperature:-55 to 105 °C
Tools/3D Models
+
3D PDF
EE ToolBox
Product Guides
+
Product Drawing - RECEPTACLE ASSEMBLY, SIZE 1, 9 POSITION, ACTION PIN , VERTICAL, FRONT METAL SHELL
Datasheet
Product Specification - AMPLIMITE HD-20 Connectors with ACTION PIN Contacts
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock:
842
Can Ship immediately
MOQ for In Stock Qty:
5
MOQ for out of Stock Qty:
163
8 Weeks
can ship
6/26/26
Price (USD)
Qty
Unit Price
5
$32.12
50
$32.04
100
$31.96
163
$31.88
325
$16.88
488
$11.60
650 +
$11.36
Click for Quote
Log in
to unlock special pricing
Tariffs may apply for U.S. shipments
