5745438-4

TE Connectivity / AMP Brand

09 RCPT RA/MS 454

+ see all

Datasheet Accessories Notify Me

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

Description +

09 RCPT RA/MS 454

Product Highlights:

Number of Positions = 9
Receptacle
PCB Mount Angle = Right Angle
Product Series = HD 20
With Mating Connector Lock

Potential Applications:

Search Keywords: 57454384

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

5745438-4
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536694040
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

140
Type:

D-Subminiature
Body Orientation:

Right Angle
Mounting:

Through Hole
Gender:

SKT
Termination Method:

Solder
Shell Size:

1
Number of Contacts:

9
Contact Plating:

Gold Over Nickel,Gold Over Palladium Nickel Over Nickel
Operating Temperature:

N/A

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - RECEPTACLE ASSEMBLY, SIZE 1, 9 POSITION, RIGHT ANGLE, .454 SERIES, .025 SQ POSTS, AMPLIMITE HDP

Datasheet

Product Specification - Connector, AMPLIMITE HD-20, Printed Circuit Board Mounted

Product Specification - AMPLIMITE HD-20 PCB Mounted Connector

Product Specification - AMPLIMITE HD-20 Series 454 and 545 Right-Angle Rear Load Metal Shell

Agency Approval Document - AMPLIMITE D-SUBMINIATURE TYPE CONNECTORS REPORT

Instruction Sheet - AMPLIMITE .050 Series Connectors (Round-to-Flat Cable)
