Image is representational - see mfr. specs
2-5748003-0
TE Connectivity / AMP Brand
09 PLUG SP/FMS BRDLK
Datasheet Accessories Notify Me
RoHS Compliant
Tube Packaging
Certificate of Compliance Guarantee
Description
+
09 PLUG SP/FMS BRDLK
Product Highlights:
- Number of Positions = 9
- Plug
- PCB Mount Angle = Vertical
- Product Series = HD 20
- Without Mating Connector Lock
Search Keywords: 257480030
SPECS
+
-
Product AttributeAttribute Value Select Attribute
-
Supplier:TE Connectivity / AMP Brand
-
Part No:2-5748003-0
-
Unit of Measure:Per Each
-
RoHS:Yes
-
HTS:8536694040
-
COO:MX
-
ECCN:EAR99
-
Supplier Standard Pack:
17 -
Type:D-Subminiature
-
Body Orientation:Straight
-
Mounting:Through Hole
-
Gender:Pin
-
Termination Method:Solder
-
Shell Size:1
-
Number of Contacts:9
-
Contact Plating:Gold over Nickel
-
Operating Temperature:-55 to 105 °C
Tools/3D Models
+
3D PDF
EE ToolBox
Product Guides
+
Product Drawing - PLUG ASSEMBLY, SIZE 1, 9 POS, VERTICAL, FRONT METAL SHELL, AMPLIMITE HD-20
Datasheet
Product Specification - Connector, AMPLIMITE HD-20, Printed Circuit Board Mounted
Product Changes
+
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock:
1,556
Can Ship immediately
On Order:
1,071
can ship 7/15/26
Minimum Order Quantity:
17
Order Increment:
17
45 Weeks
can ship
3/12/27
Price (USD)
Qty
Unit Price
17
$4.76
51
$4.72
102
$4.67
255
$4.62
510
$4.60
1,003
$4.55
2,516
$4.52
5,015 +
$4.50
