Image is representational - see mfr. specs
204512-2
TE Connectivity / AMP Brand
The 204512-2 is a military-qualified, high-density, 26-position D-subminiature receptacle supplied with size 22 socket contact ...
Datasheet Accessories Notify Me
RoHS Non-Compliant
Pack Packaging
Description
+
The 204512-2 is a military-qualified, high-density, 26-position D-subminiature receptacle supplied with size 22 socket contacts.
Product Highlights:
- Connector
- Product Series = 90
- Housing Gender = Receptacle
- Contact Gender = Socket
- Density = High
Search Keywords: 2045122
SPECS
+
-
Product AttributeAttribute Value Select Attribute
-
Supplier:TE Connectivity / AMP Brand
-
Part No:204512-2
-
Alias/AKA:M24308/2-11F
-
Unit of Measure:Per Each
-
RoHS:No
-
HTS:8536694030
-
COO:MX
-
ECCN:EAR99
-
Supplier Standard Pack:
1 -
Type:High Density D-Sub
-
Body Orientation:Straight
-
Mounting:Panel Mount
-
Gender:SKT
-
Termination Method:Crimp
-
Shell Size:1
-
Number of Contacts:15
-
Shell Plating Material:Zinc/Steel
-
Contact Plating:N/A
-
Operating Temperature:-55 to 125 °C
Tools/3D Models
+
3D PDF
EE ToolBox
Product Guides
+
Product Drawing - AMPLIMITE KIT, HDD SERIES RECEPTACLE, SIZE 1, 15 POSITION
Datasheet
Agency Approval Document - AMPLIMITE & AMPLIMITE .050
Instruction Sheet - AMPLIMITE High Density 22 (HD-22) Connectors
Product Changes
+
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock:
242
Ships today, if you order in
On Order:
9
can ship 5/6/26
35 Weeks
can ship
12/30/26
Tariffs may apply for U.S. shipments
ROHs Equivalent
