1-84533-2

Name: 1-84533-2 Te Connectivity Amp Brand FFCFPC
Brand: Te Connectivity Amp Brand
SKU: 10195048
Availability: InStock

1.25MM FFC POST PLATED H 12P

+ see all

View Datasheet Accessories Notify Me

Datasheet Assistant

Answers are limited to this part. Verify critical specs against the datasheet.

RoHS Compliant

TRAY Packaging

Certificate of Compliance

Description +

1.25MM FFC POST PLATED H 12P

Product Highlights:

1.25 mm Centerline
Number of Positions = 12
PCB Mount Angle = Right Angle
PCB Mount Style = Thru Hole
Contact Type = Top

Potential Applications:

Search Keywords: 1845332

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

1-84533-2
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536694040
COO:

CN
ECCN:

EAR99
Supplier Standard Pack:

170
Type:

FFC Connector
Number of Contacts:

12
Pitch:

2.5 mm
Mounting:

Through Hole
Termination Method:

Solder
Maximum Voltage Rating:

N/A
Maximum Current Rating:

N/A
Dimension:

18.75 x 7.8 x 4.8 mm
Operating Temperature:

N/A

Symbol, Footprint, 3D Model

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - assy, 1.25mm FFC CONN, HORIZONTAL ( POST PLATED )

Datasheet

Product Specification - 1.25mm Pitch FFC Connector (Non-ZIF Type)

Frequently Asked Questions

Is 1-84533-2 RoHS compliant?

Yes, 1-84533-2 is RoHS compliant.

What is the lead time for 1-84533-2?

The standard lead time for 1-84533-2 is approximately 18 days. In-stock quantities ship from OnlineComponents.com.
