TE Connectivity / AMP Brand
1757823-7
D Sub Connector - HD15 - 15 Contacts - Plug - Crimp - DE - AMPLIMITE 90 Series - Steel Body.
View Datasheet Ask the Datasheet Accessories Notify Me
- Connector
- Product Series = 90
- Density = High
- Terminate To Wire
- Number of Positions = 15
| Product Attribute | Attribute Value Select Attribute |
|---|---|
| Supplier: | TE Connectivity / AMP Brand |
| Part No: | 1757823-7 |
| Alias/AKA: | M24308/4-11Z |
| Unit of Measure: | Per Each |
| RoHS: | Yes |
| HTS: | 8536694030 |
| COO: | MX |
| ECCN: | EAR99 |
Supplier's Standard Package:
|
1 |
| Type: | High Density D-Sub |
| Body Orientation: | Straight |
| Mounting: | Panel Mount |
| Gender: | Pin |
| Termination Method: | Crimp |
| Shell Size: | 1 |
| Number of Contacts: | 15 |
| Shell Plating Material: | Cadmium/Steel |
3D PDF
EE ToolBox
Product Drawing - AMPLIMITE PLUG ASSY,SIZE 1 THRU 6 SERIES 90 WITH ZINC PLATED SHELLS
Datasheet
Material Declaration - MD_1757823-7_072520122319
