1658645-1

TE Connectivity / AMP Brand

D Sub Connector Housing - 9 Ways - D Sub - DE - AMPLIMITE HDP-20 Series - Plug - Steel Body.

+ see all

Datasheet Accessories Notify Me

RoHS Compliant

Bag Packaging

Certificate of Compliance Guarantee

Description +

D Sub Connector Housing - 9 Ways - D Sub - DE - AMPLIMITE HDP-20 Series - Plug - Steel Body.

Product Highlights:

Connector Kit
Product Series = HDP-20 (Crimp Snap)
Number of Positions = 9
Shielded
Plug

Potential Applications:

Search Keywords: 16586451

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

1658645-1
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8538908180
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

100
Type:

D-Subminiature
Body Orientation:

Straight
Mounting:

Cable Mount
Gender:

Pin
Termination Method:

Crimp
Shell Size:

1
Number of Contacts:

9
Contact Plating:

N/A
Operating Temperature:

-55 to 105 °C

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - KIT, PLUG, SHIELDING HARDWARE, SIZE 1, 9 POSITION, AMPLIMITE HDP-20

Datasheet

Product Specification - AMPLIMITE HDP-20 and Economy Crimp Snap Subminiature D Commercial Connectors

Product Specification - AMPLIMITE HDP-20 Subminiature D Connector With F Crimp Contacts

Agency Approval Document - AMPLIMITE & AMPLIMITE .050

Product Specification - AMPLIMITE Shielding Hardware Connector

Product Specification - AMPLIMITE HDE-20 & HDP-20 Shielding Hardware

Agency Approval Document - AMPLIMITE CONNECTOR REPORT

Instruction Sheet - Shielding Hardware Kits w/AMPLIMITE hde-20 hdp-20 and HDP-22 Connector
