Image is representational - see mfr. specs
1-5747871-3
TE Connectivity / AMP Brand
09 PLUG SP/FMS SCRLK
Datasheet Accessories Notify Me
RoHS Compliant
Tube Packaging
Certificate of Compliance Guarantee
Description
+
09 PLUG SP/FMS SCRLK
Product Highlights:
- Number of Positions = 9
- Plug
- PCB Mount Angle = Vertical
- Product Series = HD 20
- With Mating Connector Lock
Search Keywords: 157478713
SPECS
+
-
Product AttributeAttribute Value Select Attribute
-
Supplier:TE Connectivity / AMP Brand
-
Part No:1-5747871-3
-
Unit of Measure:Per Each
-
RoHS:Yes
-
HTS:8536694040
-
COO:MX
-
ECCN:EAR99
-
Supplier Standard Pack:
17 -
Type:D-Subminiature
-
Body Orientation:Straight
-
Mounting:Through Hole
-
Gender:Pin
-
Termination Method:Solder
-
Shell Size:1
-
Number of Contacts:9
-
Contact Plating:Gold over Nickel
-
Operating Temperature:-55 to 105 °C
Tools/3D Models
+
3D PDF
EE ToolBox
Product Guides
+
Product Drawing - PLUG ASSEMBLY, SIZE 1, 9 POS, VERTICAL, FRONT SHELL, AMPLIMITE HDP
Datasheet
Product Specification - AMPLIMITE HD-20 Straight Solder Contact Tine, Front Metal Shell, PC Board and Panel Mount Connectors
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock:
690
Ships today, if you order in
Minimum Order Quantity:
17
Order Increment:
17
2 Weeks
can ship
5/12/26
Price (USD)
Qty
Unit Price
17
$3.542
51
$3.454
102
$3.402
255
$3.312
510
$3.288
1,003
$3.271
2,516
$3.255
5,015 +
$3.239
Click for Quote
Log in
to unlock special pricing
Tariffs may apply for U.S. shipments
