1-5745968-6

TE Connectivity / AMP Brand

The 1-5745968-6 is a 25-position, HD-20 series, front metal-shell, straight posted subminiature D-connector plug with fixed fe ...

+ see all

Datasheet Accessories Notify Me

RoHS Compliant

Tube Packaging

Certificate of Compliance Guarantee

Description +

The 1-5745968-6 is a 25-position, HD-20 series, front metal-shell, straight posted subminiature D-connector plug with fixed female 4-40 screwlocks.

Product Highlights:

25 Positions
With Contacts
Housing Gender = Plug
PCB Mount Angle = Vertical
Product Series = HD 20

Potential Applications:

Search Keywords: 157459686

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

1-5745968-6
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536694040
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

10
Type:

D-Subminiature
Body Orientation:

Straight
Mounting:

Through Hole
Gender:

Pin
Termination Method:

Solder
Shell Size:

3
Number of Contacts:

25
Contact Plating:

Gold over Nickel
Operating Temperature:

-55 to 105 °C

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - PLUG ASSEMBLY, SIZE 3, 25 POSITION, VERTICAL, FRONT METAL SHELL, AMPLIMITE HD-20

Datasheet

Product Specification - AMPLIMITE HD-20 Straight Solder Contact Tine, Front Metal Shell, PC Board and Panel Mount Connectors

Product Specification - AMPLIMITE HD-20 PCB Mounted Connector

Product Specification - Connector, AMPLIMITE HD-20, Printed Circuit Board Mounted

Agency Approval Document - AMPLIMITE D-SUBMINIATURE TYPE CONNECTORS REPORT
