Image is representational - see mfr. specs

1375820-7

TE Connectivity / AMP Brand

CST-100 II HOUSING 7 POS

Datasheet Accessories Notify Me

RoHS Compliant

Pack Packaging

Certificate of Compliance Guarantee

Description +

CST-100 II HOUSING 7 POS

Product Highlights:

CST-100 II Housings
Number of Positions = 7
Mating Type = Receptacle
Wire-to-Board Application
2.54 mm Contact Centerline Spacing

Search Keywords: 13758207

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

1375820-7
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8538906000
COO:

CN
ECCN:

EAR99
Supplier Standard Pack

1
Mounting:

Cable Mount
Body Orientation:

Straight
Gender:

RCP
Number of Contacts:

7
Maximum Voltage Rating:

250 VAC
Maximum Current Rating:

4/Contact A
Operating Temperature:

-55 to 105 °C

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - HOUSING, CST-100 II

Datasheet

Product Specification - CST-100 Type II .100 Inch Centerline Crimp-Snap Connectors

Product Specification - Evaluation of .100 Inch Centerline Type II Crimp-Snap Terminal

Product Specification - Application Specification - CST-100 II Connectors

Product Specification - CST-100 Type II .100 Inch Centerline Crimp-Snap Connectors

Agency Approval Document - CST 100 and CST 100 II connectors

Instruction Sheet - Extracting CST-100 II Contact 1375819-[ ] from Housing 1375820-[ ]

This product is discontinued, but still in stock.
This product is NOT RoHS Compliant. See alternative
Different product options available. See alternative
Different packaging options available. See alternative
Possible Replacement options available. See alternative
Item discontinued
End of Life: Final orders must be placed by
Item discontinued

In Stock: 105,241

Can Ship immediately

Minimum Order:

100

Factory Lead-Time:

16 Weeks can ship 3/11/26

Price (USD)

Qty

Unit Price

100

$0.2562

1,000

$0.1892

2,500

$0.1804

5,000

$0.1769

7,500

$0.1743

25,000

$0.1719

50,000

$0.1710

100,000 +

$0.1702

Older Equivalent

770602-7

VIEW PRODUCT

Conn Housing RCP 7 POS 2.54mm Crimp ST Cable Mount Bag

Accessories

641214-7

Conn Wire to Board HDR 7 POS 2.54mm Solder RA Thru-Hole

3-641214-7

07P MTA100 HDR ASSY PO/RA LF

+ Show 19 More
