Image is representational - see mfr. specs

1-200833-1

TE Connectivity / AMP Brand

Connector Accessory - Guide Pin Kit - AMP M Series Pin Connectors - 4-40 UNC-2B - 11.18 mm - 21.08 mm.

Datasheet Accessories Notify Me

RoHS Compliant

Bag Packaging

Certificate of Compliance Guarantee

Description +

Connector Accessory - Guide Pin Kit - AMP M Series Pin Connectors - 4-40 UNC-2B - 11.18 mm - 21.08 mm.

Product Highlights:

Hardware
Hardware Type = Guide Pin
Guide Pin Type = Corner
None Mounting Hardware

Search Keywords: 12008331

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

TE Connectivity / AMP Brand
Part No:

1-200833-1
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

7318190000
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

100
Type:

Guide Pin
Dimension:

21.08 x 5.58 mm
Operating Temperature:

N/A

Tools/3D Models +

3D PDF

EE ToolBox

Product Guides +

Product Drawing - GUIDE PIN KIT, UNASSEMBLED, CORNER, MINIATURE RECTANGULAR, M SERIES

Datasheet

Material Declaration - MD_1-200833-1_05142018145_dmtec

Product Changes +

PCN - 13-Apr-2022 - Process Change Notification

PCN - 15-Apr-2015 - MANUFACTURING LOCATION CHANGE(S)

Product Change Notification

This product is discontinued, but still in stock.
This product is NOT RoHS Compliant. See alternative
Different product options available. See alternative
Different packaging options available. See alternative
Possible Replacement options available. See alternative
Item discontinued
End of Life: Final orders must be placed by
Item discontinued

In Stock: 2,649

Ships today, if you order in

MOQ for In Stock Qty:

MOQ for out of Stock Qty:

1000

Factory Lead-Time:

5 Weeks can ship 6/2/26

Price (USD)

Qty

Unit Price

$6.96

250

$5.73

500

$5.69

1,000

$5.42

2,000

$5.40

3,000

$5.39

4,000 +

$5.38

Tariffs may apply for U.S. shipments
