AE101MD1AB by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

AE101MD1AB

TE Connectivity / Alcoswitch Brand

Switch Toggle ON None ON SPDT Short Bat Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket

+ see all

Datasheet Accessories Notify Me

RoHS Compliant
Discontinued
Packaging
Certificate of Compliance Guarantee
Description +
Switch Toggle ON None ON SPDT Short Bat Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Bracket
Search Keywords: AE101MD1AB
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    TE Connectivity / Alcoswitch Brand
  • Part No:
    AE101MD1AB
  • Alias/AKA:
    1437556-8
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536509065
  • ECCN:
    EAR99
  • Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    25
  • Pole Throw Configuration:
    1P2T (SPDT)
  • Switch Configuration:
    On None On
  • Contact Rating @ Voltage:
    0.4@20VAC 20VDC A
  • Actuator Style:
    Short Bat Lever
  • Mounting:
    PC Mount with Bracket
  • Thread Size:
    N/R
  • Body Orientation:
    Right Angle
  • Terminal Type:
    PC Pins
  • Dimension:
    12.7 x 27.31 x 6.6 mm
  • Operating Temperature:
    -20 to 85 °C
Tools/3D Models +
Product Guides +

  • This product is discontinued, but still in stock.

Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 128
Ships today, if you order in
Minimum Order:
25
Order Increment:
25
ADD TO CART
Price (USD)
Qty
Unit Price
25
$23.01
50
$21.77
75 +
$16.97
Suppliers Standard Package
Click for Quote
Log in to unlock special pricing
Older Equivalent
AE101MD1AB04
AE101MD1AB04
VIEW PRODUCT
Switch Toggle ON None ON SPDT Short Bat Toggle PC Pins 20VAC 20V
