Image is representational - see manufacturer specifications

sensata / crydom
Authorized Distributor

Sensata / Crydom Authorized Distributor

D2425P

Name: D2425P Sensata Crydom Solid State Relays
Brand: Sensata Crydom
SKU: 47469222
Availability: BackOrder

Solid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 25 A - 4 Pins - ...

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

RoHS Compliant

EACH Packaging

Certificate of Compliance

Description +

Solid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 25 A - 4 Pins - 1 Form A - Screw Termination

Product Highlights:

Potential Applications:

Search Keywords: D2425P

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

Sensata / Crydom
Part No:

D2425P
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536490080
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

20
Output Type:

AC
Maximum Output Voltage:

280(RMS) V
Maximum Output Current:

25(RMS) A
Output Device:

SCR
Input Type:

DC
Mounting:

Screw
Circuit Arrangement:

1 Form A
Dimension:

44.5 x 57.3 x 22.6 mm

Symbol, Footprint, 3D Model

Tools/3D Models +

EE ToolBox

Product Guides +

Datasheet

Selecting a SSR

Why use an SSR

SSR Information

Frequently Asked Questions

What replaces D2425P?

The recommended replacement for D2425P is CSW2425P from Sensata / Crydom, available from OnlineComponents.com.

Is D2425P RoHS compliant?

Yes, D2425P is RoHS compliant.

What is the lead time for D2425P?

The standard lead time for D2425P is approximately 19 days. In-stock quantities ship from OnlineComponents.com.
