Available Replacements
Alternative Packaging
AGN200S12Z
AGN200S12Z

Panasonic Electronic Components

In Stock: 0

Minimum Order: 5

View Product
AGN200S12 by panasonic electronic components
Image is representational - see manufacturer specifications

Panasonic Electronic Components Authorized Distributor

AGN200S12

Signal Relay 12VDC 1.028KOhm 1A DPDT(10.6mm 5.7mm 10mm) SMD General Purpose Relay

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

RoHS Compliant
Packaging
Certificate of Compliance
Description +
Signal Relay 12VDC 1.028KOhm 1A DPDT(10.6mm 5.7mm 10mm) SMD General Purpose Relay
Search Keywords: AGN200S12
SPECS +
Product Attribute Attribute Value Select Attribute
Supplier: Panasonic Electronic Components
Part No: AGN200S12
Unit of Measure: Per Each
RoHS: Yes
HTS: 8536410020
COO: JP
ECCN: EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution. 50
Relay Construction: Non-Latching
DC Coil Voltage: 12 V
Contact Arrangement: DPDT
Maximum Current Rating: 1 A
Mounting: Surface Mount
Operating Temperature: -40 to 85 °C
Dimension: 10.6 x 5.7 x 10 mm
Termination Style: Gull Wing
Coil Current: 11.7 mA
Contact Form: 2 Form C
Symbol, Footprint, 3D Model
Tools/3D Models +
Frequently Asked Questions
Is AGN200S12 RoHS compliant?
Yes, AGN200S12 is RoHS compliant.
What is the lead time for AGN200S12?
The standard lead time for AGN200S12 is approximately 52 weeks. In-stock quantities ship from OnlineComponents.com.

Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 3,000
Can Ship immediately
Minimum Order Quantity:
3
52 Weeks can ship 11/1/27
ADD TO CART
Request Quote
Price (USD)
Qty
Unit Price
3
$2.30
10
$2.05
25
$1.90
50
$1.84
100
$1.64
250
$1.62
500
$1.61
1,000 +
$1.37
Supplier's Standard Package
Click for Quote
