ATF22V10B-15GM/883 by microchip technology
Image is representational - see manufacturer specifications

Microchip Technology Authorized Distributor

ATF22V10B-15GM/883

SPLD ATF22V10B Family 500 Gates 10 Macro Cells 83.3MHz 5V 24-Pin CDIP Tube

+ see all

View Datasheet Accessories Notify Me

RoHS Compliant
TUBE Packaging
Certificate of Compliance
This product may require extra documentation. Shipping may be delayed 1-2 days.
Description +
SPLD ATF22V10B Family 500 Gates 10 Macro Cells 83.3MHz 5V 24-Pin CDIP Tube
Search Keywords: ATF22V10B15GM883
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    Microchip Technology
  • Part No:
    ATF22V10B-15GM/883
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8542310065
  • COO:
    TH
  • ECCN:
    3A001.a.2.c
  • Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
    15
  • Dimension:
    32.51(Max) x 7.87(Max) x 3.56(Max) mm
  • Maximum Number of User I/Os:
    10
  • In-System Programmability:
    No
  • Maximum Internal Frequency:
    83.3 MHz
  • Maximum Operating Supply Voltage:
    5.5 V
  • Fabrication Technology:
    N/A
  • Device System Gates:
    500
  • Family:
    ATF22V10B
  • Family Name:
    ATF22V10B
  • Maximum Operating Current:
    120 mA
Symbol, Footprint, 3D Model
Tools/3D Models +
Product Guides +
Frequently Asked Questions
Is ATF22V10B-15GM/883 RoHS compliant?
Yes, ATF22V10B-15GM/883 is RoHS compliant.
What is the lead time for ATF22V10B-15GM/883?
The standard lead time for ATF22V10B-15GM/883 is approximately 27 weeks. In-stock quantities ship from OnlineComponents.com.
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 39
Can Ship immediately
On Order:
75   can ship 1/25/27
MOQ for out of Stock Qty:
4
27 Weeks can ship 5/3/27
ADD TO CART
Request Quote
Price (USD)
Qty
Unit Price
1
$118.38
4
$111.80
8
$109.37
12
$105.92
15 +
$105.65
Supplier's Standard Package
