MEAN WELL
PLC-100-27
AC/DC LED Power Supply - Const Curr/Volt - 95.85W - Adj: 27 Vdc @ 3,550mA - Dim: No
View Datasheet Ask the Datasheet Accessories Notify Me
| Product Attribute | Attribute Value Select Attribute |
|---|---|
| Supplier: | MEAN WELL |
| Part No: | PLC-100-27 |
| Unit of Measure: | Per Each |
| RoHS: | Yes |
| HTS: | 8504409520 |
| COO: | CN |
| ECCN: | EAR99 |
Supplier's Standard Package:
|
1 |
| Input/Output Type: | AC/DC |
| Style: | Enclosed |
| Type: | Constant Current/Voltage |
| Output Type: | Adjustable |
| Dimming: | No |
| Maximum Output Power: | 95 W |
| Output Voltage Range: | 20.25 to 27 VDC |
| Maximum Output Current: | 3,550 mA (3.55 A) |
| Minimum AC Input Voltage: | 90 |
| Maximum AC Input Voltage: | 264 |
| Minimum DC Input Voltage: | 127 |
| Maximum DC Input Voltage: | 370 |
| Termination Style: | Terminal Block |
| Input Connector Type: | Screw Clamp Terminal Block - Covered |
| Output Connector Type: | Terminal Block - Covered |
| Operating Temperature: | -30 to 50 °C |
| Safety Agency Approvals: | CB, CCC, CE, cRUus, PSE, TUV |
| NEC Class: | 2 |
| IEC Class: | None |
| SELV: | Yes |
| LPS: | Yes |
| Warranty: | 2 Years |
| Family: | PLC-100 |
-
