APD-3CP-K2 by itt cannon
Image is representational - see manufacturer specifications

ITT CANNON Authorized Distributor

APD-3CP-K2

green, 4-way APD Jam Nut Receptacle,

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

RoHS Compliant
Packaging
Certificate of Compliance
Description +
green, 4-way APD Jam Nut Receptacle,
Search Keywords: APD3CPK2
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    ITT CANNON
  • Part No:
    APD-3CP-K2
  • Alias/AKA:
    121583-0010
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8538906000
  • COO:
    DE
  • ECCN:
    EAR99
  • Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
    100
  • Gender:
    Pin
  • Static Load, Free Connector:
    350 N (ISO 15170-2, Sec. 4.6)
  • Industrial Climate:
    SO2, 0,67 %
  • Temperature Range:
    -40 °C up to 140 °C (ISO 15170-2, Sec. 6.4), 30g
  • Coupling Torque:
    1,2 Nm max
  • Voltage Proof:
    1000 VAC, 60 seconds
  • Insulator Resistance:
    10 MΩ min.
  • Vibration Resistance:
    Sine, 300 m/s², 3 x 100h, RT and 120°C (ISO 15170-2)
  • Sealing:
    IP 67 (DIN EN 60529)
  • Humidity Range:
    up to 95 %
  • Salt Spray:
    96 h, 35 °C (ISO 15170-2, Sec. 6.2)
  • Static Load, Mated Connector:
    250 N axial, 150 N lat. (ISO 15170-2, Sec. 4.5)
  • Durability Rating:
    50 Mating Cycles
  • Operating Voltage:
    48 VDC
  • Coupling Nut Material:
    PA 66 GF
  • Contact Resistance:
    5 mΩ max
  • Operating Current:
    see derating curve (catalog)
  • Housing Material:
    PBT GF
  • Connector Type:
    Jam Nut Receptacle
  • Series:
    APD 4-way
  • Fluid Compatibility:
    Brakefluid, ATF, fuel, .. (ISO 15170-2, Sec. 6.6)
  • Coding (Mechanical Keying And Visual Color Coding):
    Code 3 - green (RAL 6029)
  • Sealing Material:
    HNBR (alternative FKM)
Symbol, Footprint, 3D Model
Tools/3D Models +
Frequently Asked Questions
Is APD-3CP-K2 RoHS compliant?
Yes, APD-3CP-K2 is RoHS compliant.
What is the lead time for APD-3CP-K2?
The standard lead time for APD-3CP-K2 is approximately 10 weeks. In-stock quantities ship from OnlineComponents.com.
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 375
Can Ship immediately
MOQ for In Stock Qty:
100
MOQ for out of Stock Qty:
100
10 Weeks can ship 1/6/27
ADD TO CART
Request Quote
Price (USD)
Qty
Unit Price
100
$12.18
125
$12.15
250
$7.48
375
$5.92
500 +
$5.80
