V7-7B19E9

Honeywell

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 11 A 125, 250, or 277 Vac, Pin Plunger, 22 ...

+ see all

Datasheet Accessories Notify Me

RoHS Compliant

Packaging

Certificate of Compliance Guarantee

Description +

MICRO SWITCH™ Miniature Basic Switches: V7 Series, Single Pole Double Throw (SPDT), 11 A 125, 250, or 277 Vac, Pin Plunger, 227 g [8 oz] Maximum Operating Force, 2,9 mm [0.11 in] Mounting Holes, -40 °C to 85 °C [-40 °F to 185 °F] Temperature Range, 6,35 mm x 0,81 mm [0.250 in x 0.032 in] Quick Connect Spread Termination, UL, CSA

Product Highlights:

Best suited for higher cost-of-failure applications
Designed for 100K operations at a full load or 10M for mechanical life
World-wide package size acceptance
Current rating ranges from 0.1 A to 25 A
UL/CSA and ENEC approvals

Potential Applications:

Appliances
Vending machines
Timing devices
Office equipment
Computer/business equipment
Test instruments
Medical/dental equipment
Communications equipment
HVAC equipment
Manually operated devices
Valves
Gaming equipment
Pressure switches

Search Keywords: V77B19E9

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

Honeywell
Part No:

V7-7B19E9
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

85365080
COO:

MX
ECCN:

EAR99
Supplier Standard Pack:

200
Mounting:

Through Hole
Pole Throw Configuration:

SPDT
Switch Configuration:

N.O./N.C.
Actuator Material/Style:

Plastic/Plunger
Contact Rating @ Voltage:

11@277VAC A
Maximum Movement Differential:

0.25 mm
Operating Force:

2.22 N
Termination Style:

Quick Connect
Dimension:

39.37 x 10.16 x 23.72 mm
Body Orientation:

Straight
IP Rating:

N/A
