PS1024ARED

Name: PS1024ARED ESwitch Push Button Switches
Brand: ESwitch
SKU: 11260878
Availability: BackOrder

Pushbutton Switch - SPST-NO - Standard - 3A - 125VAC - Red Round Button Actuator - Solder Lug - Rear Panel Mount.

+ see all

View Datasheet Ask the Datasheet Accessories Notify Me

Datasheet Assistant

Answers are limited to this part. Verify critical specs against the datasheet.

RoHS Compliant

Packaging

Certificate of Compliance

Description +

Pushbutton Switch - SPST-NO - Standard - 3A - 125VAC - Red Round Button Actuator - Solder Lug - Rear Panel Mount.

Product Highlights:

Potential Applications:

Search Keywords: PS1024ARED

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

E-Switch
Part No:

PS1024ARED
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536509033
COO:

CN
ECCN:

EAR99
Supplier's Standard Package:

200
Mounting:

Panel Mount
Pole Throw Configuration:

SPST
Bushing Type:

Threaded
Switch Configuration:

Off (On)
Contact Rating @ Voltage:

3A@125 VAC
Actuator Style:

Round Button
Illumination:

N/R
Terminal Type:

Solder
Body Orientation:

Straight

Symbol, Footprint, 3D Model

Tools/3D Models +

EE ToolBox

Product Guides +

Datasheet

Frequently Asked Questions

Is PS1024ARED RoHS compliant?

Yes, PS1024ARED is RoHS compliant.

What is the lead time for PS1024ARED?

The standard lead time for PS1024ARED is approximately 12 weeks. In-stock quantities ship from OnlineComponents.com.
