EG1224 by e-switch
Image is representational - see manufacturer specifications

E-Switch Authorized Distributor

EG1224

Switch Slide SPDT Extended Side Slide PC Pins Bracket Mount/PCB Through Hole

+ see all

View Datasheet Accessories Notify Me

RoHS Compliant
Packaging
Certificate of Compliance
Description +
Switch Slide SPDT Extended Side Slide PC Pins Bracket Mount/PCB Through Hole
Search Keywords: EG1224
SPECS +
  • Product Attribute
    Attribute Value Select Attribute
  • Supplier:
    E-Switch
  • Part No:
    EG1224
  • Unit of Measure:
    Per Each
  • RoHS:
    Yes
  • HTS:
    8536509050
  • COO:
    CN
  • ECCN:
    EAR99
  • Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
    250
  • Mounting:
    PCB Through Hole
  • Body Orientation:
    Right Angle
  • Actuator Style:
    Extended Side Slide
  • Pole Throw Configuration:
    SPDT
  • Switch Configuration:
    N/A
  • Contact Rating @ Voltage:
    N/A
  • Contact Plating:
    Silver
  • Operating Temperature:
    -20 to 70 °C
  • Termination Style:
    PC Pins
  • Dimension:
    13.8 x 15.5 x 8.5 mm
Symbol, Footprint, 3D Model
Tools/3D Models +
Product Guides +
Frequently Asked Questions
Is EG1224 RoHS compliant?
Yes, EG1224 is RoHS compliant.
What is the lead time for EG1224?
The standard lead time for EG1224 is approximately 15 weeks. In-stock quantities ship from OnlineComponents.com.
Price Match Guarantee
We’ll meet or beat any authorized competitor’s published price for this part.
In Stock: 1,248
Can Ship immediately
Minimum Order Quantity:
250
Order Increment:
250
15 Weeks can ship 12/21/26
ADD TO CART
Price (USD)
Qty
Unit Price
250
$0.6181
500
$0.5786
1,000
$0.5435
2,500
$0.5048
5,000
$0.4808
7,500
$0.4796
10,000
$0.4784
15,000 +
$0.4772
Supplier's Standard Package
Click for Quote
Log in to unlock special pricing
