646H

Name: 646H Apem Inc Toggle Switches
Brand: Apem Inc
SKU: 10574545
Availability: InStock

Switch Toggle, DPDT, Round Lever, Terminal Stule: Screw, Current: 10A, Voltage: 125VAC, Panel Mount

+ see all

View Datasheet Accessories Notify Me

Datasheet Assistant

Answers are limited to this part. Verify critical specs against the datasheet.

RoHS Compliant

Packaging

Certificate of Compliance

Description +

Switch Toggle, DPDT, Round Lever, Terminal Stule: Screw, Current: 10A, Voltage: 125VAC, Panel Mount

Product Highlights:

Potential Applications:

Search Keywords: 646H

SPECS +

Product Attribute

Attribute Value Select Attribute
Products found: 0 Show Similar
Supplier:

APEM Inc.
Part No:

646H
Unit of Measure:

Per Each
RoHS:

Yes
HTS:

8536509050
COO:

FR
ECCN:

EAR99
Supplier Standard Pack:

25
Pole Throw Configuration:

2P2T (DPDT)
Switch Configuration:

On None On
Contact Rating @ Voltage:

15@250VAC 12VDC A
Actuator Style:

Round Lever
Mounting:

Panel Mount with Threads
Thread Size:

M12 x 0.75
Body Orientation:

Straight
Terminal Type:

Screw
Dimension:

29.7 x 21.5 x 60.4 mm
Operating Temperature:

-20 to 55 °C

Symbol, Footprint, 3D Model

Tools/3D Models +

EE ToolBox

Product Guides +

Datasheet

Component Moment Extended Cut: APEM High Performance Toggles

Learn more about APEM, Inc. High Performance Toggle Series

Frequently Asked Questions

Is 646H RoHS compliant?

Yes, 646H is RoHS compliant.

What is the lead time for 646H?

The standard lead time for 646H is approximately 10 days. In-stock quantities ship from OnlineComponents.com.
